About the SY245H
The SY245H is a 25.5-tonne crawler excavator for earthmoving, road construction, mining, trenching and lifting. A 1.3 m³ bucket and 6,705 mm dig depth cover a wide spread of site work.
A Mitsubishi D06FRC diesel makes 147 kW at 2100 rpm, giving digging forces of 175 kN (bucket) and 120 kN (arm). Hydraulic flow tops out at 520 L/min. An extra-large standalone radiator and anti-corrosion coatings help it last in harsh conditions, and SANY rates the control system at up to 10% lower fuel use.
Specifications
- Make and model
- SANY SY245H
- Engine
- Mitsubishi D06FRC
- Max Torque
- 750Nm / 1350rpm
- Max Oil Flow
- 520 L/Min
- Hydraulic Pump
- Kawasaki, Adjustable axial piston pump
- Power
- 147 kW
- Operating weight
- 25,500 kg
- Fuel
- Diesel
Manufacturer figures for the standard machine. Options and attachments change some of them; we confirm the exact spec with your quote, and the brochure is yours on request.
SANY SY245H
A 26 tonne excavator, Mitsubishi D06FRC at 147 kW.
Priced on request. Attachments and options change the number, so tell us what you need it for and we'll quote it properly.
